Solution Proposal from Mitutoyo

Measuring Minute Shapes Once Thought Impossible?

　 -Micro-shape measuring system　 UMAP Vision System

Mitutoyo's Minute Shape Measuring System Effectively Addresses the Following Challenges:

• Lack of styluses smaller than 0.5 mm, making the evaluation of minute shapes impossible.

• Excessive contact pressure in three-dimensional measuring machines, causing deformation of the workpiece during measurement.

Challenge: Corner Radii of Minute Shapes and Cross-Sectional Shapes Cannot be Accurately Evaluated

Challenge: Soft Materials, such as Rubber and Thin Film Products, Deform Under Pressure During Measurement

Need help solving a measurement problem? Contact us anytime!

Related Solutions and Applications

MiSCAN Vision System - Micro-Form Measuring System with Scanning Probe

The MiSCAN Vision System, with a micro-stylus tip as small as 125 µm, enables precise scanning of micro-forms and excels in measuring minute parts of precision punches and dies with nano-stylus options.

FORMTRACER Avant Series - Surface Roughness and Contour Measuring Instrument

The FORMTRACER Avant series offers versatile models that simplify setup and alignment, reduce workpiece securing time, and allow seamless conversion between contour and surface roughness measurement by retrofitting detectors after installation, ensuring precise measurements even in narrow areas.

ROUNDTRACER EXTREME - Roundness/Cylindrical Shape Measuring System

The ROUNDTRACER EXTREME provides exceptional repeatability in roundness and cylindrical shape measurements while also measuring surface roughness and contours, making it perfect for evaluating prototype shaft-type products.
